The ToupTek SC335C Microscope Eyepiece Camera is one of the SCMOS range of microscope eyepiece cameras. It incorporates a Sony IMX335 colour sensor, and communicates with a computer through a USB cable.

The ToupTek SC335C is simple and compact, with no need for additional optical adapters. Using the correct adapter ring, the camera can be used instead of an eyepiece in microscopes with 23.2mm, 30mm, 30.5mm or 30.75mm eyepieces.

The SCMOS camera body is made from aluminium alloy, which ensures a heavy duty, workhorse solution with no moving parts. The camera has a high quality IR-CUT filter to filter the infrared light and protect the camera sensor. This design ensures a rugged, robust solution with an increased lifespan when compared to other industrial camera solutions.

The USB2.0 interface provides a frame rate that allows you to watch your subject on your computer screen without interruption.

Included with the camera is the advanced video and image processing application ToupView.

Specifications of the ToupTek SC335C

ToupTek part number TP505100B
Sensor name Sony IMX335
Size class 1/2.8″
Size (mm) 5.18 x 3.89
Full resolution (px) 2592 x 1944
Diagonal (mm) 6.52
Megapixels 5.1
C/M Colour
Pixel size (µm) 2.0
Download speed (FPS) 20
ADC 10 bit (12 bit)



Contents:

  • ToupTek S3C335C camera (23.2mm diameter eyepiece tube)
  • ToupView software, utilities and drivers (may be delivered on a USB stick)
  • USB2 cable

Optional accessories:

  • Adapter ring for 30mm eyepiece tube
  • Adapter ring for 30.5mm eyepiece tube
  • Adapter ring for 30.75mm eyepiece tube
  • Calibration kit
